G-SE SMS alarm controller

G-SE SMS alarm controller

SMS alarm controller.

Alarm via SMS

• Smoke detector
• Motion detector
• Water sensor
• Temperature / RH monitoring
• Magnetic contacts (for windows, doors, etc)
• Power failure
• GSE over-temperature timer box
• External alarm system

Fuctions:

• Automatic sensor detection at each of the ten ports.
• Data transmission security adjustable from normal to encoded
• SMS control of up to ten 230 V multi-socket outlets
• Minimum and maximum temperature and air humidity adjustable via SMS.
• Storage for up to two phone numbers
• Retrievable controller status
• Language selection German / English
• Adjustable delay time (0 … 180 seconds) before alarm is armed
• Use of external key switch is possible

The controller is an easy-to-use standalone alarm system with alarm output via SMS. The device provides ten independent input / output ports.

By virtue of its many sensors and its individual terminal assignment, the controller meets all requirements. The controller offers additional functions such as the option to store a second phone number and to switch any standard 230 V device on or off via SMS.

Sizes and technical data's:

• Power adapter: 100 – 240 V / 50 – 60 Hz
• Supply voltage: 12 VDC +/- 10 %
• Supply current: Min. 500 mA
• Temperature range: 10 °C to 50 °C
• Humidity range: 0 % to 95 %
• GSM frequencies: 900 / 1800 / 1900 MHz
• Dimensions (L x W x H): 80 x 140 x 78 mm
