SJ - Extractor EC 150 m³/h (DF16E150)

Secret Jardin - Extractor EC 150 m³/h (DF16E150)

Secret Jardin Extractor Designed to clip on to the DUCTING FLANGE system.

Designed to clip on to our DUCTING FLANGE system, it takes less than 5 seconds to assemble without any tools. Use it in combination with our DF16 filter for optimal assembly! This product includes temperature control functions (T°, Max/min extractor speed) and 2 thermal sensors (onboard or external) depending on the size of your grow space.

Thanks to this DF16150K adapter kit (sold separately), use your SJ filter or extractor with classic ductings (150mm), in a tent that is not equipped with DF16 technology.

Included

• Extractor DF16E150
• Adapator DF16 Ring
• 2nd Thermal Sensor (external)
• 24V Deported Power Supply

Technology

• EC MOTOR
• Max/Min AirFlow

Reference

DF16E150

Weight

0.8kg

Dimensions

22cm x 18cm x 10cm

Module Power

• Consumption : 15 W
• Voltage : 24 V
• Current : 0.6 A

Power Supply Cable & Plugs

• 24V Cable : 240cm
• 110V-220V Cable : 60cm
• Voltage : 110-220 V
• Frequence : 50/60 Hz

Noise *

• Ext Max 50m3/h: 20 dB
• Ext Max 100m3/h: 40 dB
• Ext Max 150m3/h: 55 dB

* Extractor & Filter in the grow tent. Measurement taken 70cm in front of the grow tent.

Raw Materials

Enclosure made of flame resistant polyamide reinforced with glass fiber (PA66 + 15%GF V0).
