Can-Fan Digital EC Fan Controller (LCD)

Can-Fan Digital EC Fan Controller (LCD)

Can Fan LCD EC Controller is the perfect controller for the Max Fan Pro Series EC and Q Max EC.

The controller is equipped with a plug & play jack system for easy handling. Operation is very user-friendly thanks to the up / down buttons and is child's play thanks to the 17-language manual.

The following functions can be controlled with the Can Fan LCD EC controller:

• Temperature
• Temperature Hysteresis
• Humidity
• Humidity Hysteresis
• Minimum Speed
• Maximum Speed
• Day Time
• Night Time
• Negative Pressure

The 12V DC power supply is included, as well as all necessary cables (4 meters) and plugs, as well as a sensor for humidity / day and night / temperature.

The connection to the fan is made via the included jack plug.

Connections :

• Exhaust fan (Fan1)
• Intake fan (Fan2)
• Sensor (temperature and humidity)
• Power supply (12V DC)

Delivery :

• Can EC Fan Controller
• Sensor (temperature and humidity)
• Power supply (12V)
• 2x 4m cable with jack for EC fans

The device only works on fans with an EC motor!
