SJ - Charcoal Filter 150 m³/h (DF16F150)

Secret Jardin - Charcoal Filter 150 m³/h (DF16F150)

Secret Jardin Charcoal Filter Designed to clip on to the DUCTING FLANGE system.

Designed to clip on to our DUCTING FLANGE system, it takes less than 5 seconds to assemble without any tools. Use it in combination with our DF16 Extractor for optimal assembly! Our DF16 Filter are full filled with CTC80 carbon and are equipped with a pre-filter.

Reference

DF16F150

Weight

1.5kg

Dimensions

Ø22.5cm x 13cm

Carbon

• Type : CTC-80
• Diam. : 3mm
• Weight : 1,0kg
• Carbon bed tickness : 3cm

Set up

• Tent réf. : DS60
• Vol : 0.6m3
• Max Ext. : 150m3/h

Air Flow measured *

With DF16E350 Extractor at 150m3/h max potentiometer value.

Ext. alone :

• 155m3/h
• Cycle/min : 4,5

Ext + Filtre :

• 85m3/h
• Cycle/min : 2,4

Ext + Filtre + Light Baffle :

• 65m3/h
• Cycle/min : 1,9

* Cycle / min: The number of times the volume of air in the tent will be renewed per minute.
